●7000Wh BYD battery pack for solar ESS.
●6000 cycles, life time can be over 15 years.
●Matched inverter: Guruwat, GOODWE, SOFAR, DeYe, Voltronic Power, EAST, SMA
●Adorable ID design.
●Wall-mounted, save installation space.
| Item No. | KLF-B7K-A |
|---|---|
| Item No. | 51.2V |
| Rated Voltage | 135Ah |
| Single Battery Energy （1/3Cmin, Ah） | 7000Wh |
| Rated Envergy (Wh) | 20A @ 23°C |
| Standard Charging Current (A) | 135A @ 23°C |
| Max Continuous Charge Current (A) | 3.65V/Cell |
| Charge Cut-off Voltage | 2.00V/Cell |
| Disharge Cut-off Voltage | 20A @ 23°C |
| Standard Discharge Current(A) | 100A @ 23°C |
| Max Continuous Disharge Current (A) | 7kW（BOL/23°C/50%SOC/5S） |
| Max Charge Power | 10.5kW（BOL/23°C /50%SOC/5S） |
| Max Disharge Power | -20~+50℃ |
| Charge Temperature | -30~+55℃ |
| Charge Temperature | -20-+35℃（<3 months,20~60% SOC） |
| Short-time Storate Temperature | -20-+30℃（<1YEAR，30~60% SOC） |
| Long-time Storate Temperature | 5%~95% |
| Storage Humidity | 65℃ |
| Over-hot Protection | > 6000 times |
| Battery cycle life | 1100*850*700MM/92.5MM |
| Product Size | 47.5±0.05 Kgs |
